moveit2
The MoveIt Motion Planning Framework for ROS 2.
Public Member Functions | Static Public Attributes | List of all members
ompl_interface::JointModelStateSpace Class Reference

#include <joint_model_state_space.h>

Inheritance diagram for ompl_interface::JointModelStateSpace:
Inheritance graph
[legend]
Collaboration diagram for ompl_interface::JointModelStateSpace:
Collaboration graph
[legend]

Public Member Functions

 JointModelStateSpace (const ModelBasedStateSpaceSpecification &spec)

const std::string & getParameterizationType () const override

- Public Member Functions inherited from ompl_interface::ModelBasedStateSpace
 ModelBasedStateSpace (ModelBasedStateSpaceSpecification spec)

 ~ModelBasedStateSpace () override

void setInterpolationFunction (const InterpolationFunction &fun)

void setDistanceFunction (const DistanceFunction &fun)

ompl::base::State * allocState () const override

void freeState (ompl::base::State *state) const override

unsigned int getDimension () const override

void enforceBounds (ompl::base::State *state) const override

bool satisfiesBounds (const ompl::base::State *state) const override

void copyState (ompl::base::State *destination, const ompl::base::State *source) const override

void interpolate (const ompl::base::State *from, const ompl::base::State *to, const double t, ompl::base::State *state) const override

double distance (const ompl::base::State *state1, const ompl::base::State *state2) const override

bool equalStates (const ompl::base::State *state1, const ompl::base::State *state2) const override

double getMaximumExtent () const override

double getMeasure () const override

unsigned int getSerializationLength () const override

void serialize (void *serialization, const ompl::base::State *state) const override

void deserialize (ompl::base::State *state, const void *serialization) const override

double * getValueAddressAtIndex (ompl::base::State *state, const unsigned int index) const override

ompl::base::StateSamplerPtr allocDefaultStateSampler () const override

const moveit::core::RobotModelConstPtr & getRobotModel () const

const moveit::core::JointModelGroupgetJointModelGroup () const

const std::string & getJointModelGroupName () const

const ModelBasedStateSpaceSpecificationgetSpecification () const

void printState (const ompl::base::State *state, std::ostream &out) const override

void printSettings (std::ostream &out) const override

virtual void setPlanningVolume (double minX, double maxX, double minY, double maxY, double minZ, double maxZ)
 Set the planning volume for the possible SE2 and/or SE3 components of the state space. More...

const moveit::core::JointBoundsVectorgetJointsBounds () const

virtual void copyToRobotState (moveit::core::RobotState &rstate, const ompl::base::State *state) const
 Copy the data from an OMPL state to a set of joint states. More...

virtual void copyToOMPLState (ompl::base::State *state, const moveit::core::RobotState &rstate) const
 Copy the data from a set of joint states to an OMPL state. More...

virtual void copyJointToOMPLState (ompl::base::State *state, const moveit::core::RobotState &robot_state, const moveit::core::JointModel *joint_model, int ompl_state_joint_index) const
 Copy a single joint's values (which might have multiple variables) from a MoveIt robot_state to an OMPL state. More...

double getTagSnapToSegment () const

void setTagSnapToSegment (double snap)


Static Public Attributes

static const std::string PARAMETERIZATION_TYPE = "JointModel"


Additional Inherited Members

- Protected Attributes inherited from ompl_interface::ModelBasedStateSpace
ModelBasedStateSpaceSpecification spec_

std::vector< moveit::core::JointModel::Boundsjoint_bounds_storage_

std::vector< const moveit::core::JointModel * > joint_model_vector_

unsigned int variable_count_

size_t state_values_size_

InterpolationFunction interpolation_function_

DistanceFunction distance_function_

double tag_snap_to_segment_

double tag_snap_to_segment_complement_


Detailed Description

Definition at line 43 of file joint_model_state_space.h.

Constructor & Destructor Documentation

◆ JointModelStateSpace()

ompl_interface::JointModelStateSpace::JointModelStateSpace ( const ModelBasedStateSpaceSpecification spec)

Definition at line 41 of file joint_model_state_space.cpp.

Member Function Documentation

◆ getParameterizationType()

const std::string& ompl_interface::JointModelStateSpace::getParameterizationType ( ) const
inlineoverridevirtual

Implements ompl_interface::ModelBasedStateSpace.

Definition at line 50 of file joint_model_state_space.h.

Member Data Documentation

◆ PARAMETERIZATION_TYPE

const std::string ompl_interface::JointModelStateSpace::PARAMETERIZATION_TYPE = "JointModel"
static

Definition at line 46 of file joint_model_state_space.h.


The documentation for this class was generated from the following files:
